GS large circular saw blades with wipers

HM circular saw blades with wipers for the first wood processing

For the longitudinal cut of:

• softwood
• hardwood
• exotic wood

Body blades steel
Steel used for the construction of the body blades is hot or cold rolled.
There are two main categories:

• 80CrV2: for medium / high applications with high stress
• 75Cr1: for standard applications

Teeth
The choice of high quality carbide, to be used for cutting different materials, is directed towards various types of quality of micro / fine / medium grain inserts, to ensure greater durability of the circular blade, greater resistance to shocks and limited wear of the tooth.

The cutting thickness is increased and radial and tangential angles are accentuated to have a better penetration and a greater dumping of the chip, avoiding the lateral kneading of the body blade.

To be used on trimming machines and beams sawing centers:

• Speed of use 60-85 m / s
• High speed cutting feed depends on the number of teeth, the section and the quality of the material to be cut
• From 35 m / min to 65 m / min
• Maximum cutting performance



Type GS
Diameter	ST	SC	Teeth + Wipers
520	5,0	3,5	60 + 6
550	5,0	3,5	40 + 4
600	5,5	3,8	48 + 8
630	5,5	3,8	36 + 8
650	5,5	3,8	54 + 6
700	5,5	3,8	48 + 8
730	6,0	4,0	60 + 6
750	6,5	4,5	72 + 6
760	6,5	4,5	72 + 6
800	6,5	4,5	72 + 8
850	7,0	5,0	72 + 8
900	7,0	5,0	60 + 8
1000	7,0	5,0	90 + 8
1200	8,0	6,0	90 + 8

Central bore and pin-holes available for all types of machines.
Execution of different sharpening geometries, use of various teeth quality and coatings.
Number of wipers depends on the application.
